Core Components
Manufacturer's self-developed weighing controller; high-precision load cell
Weighing Platform Specifications
250mm (L) × 168mm (W)
Detection Speed
Approx. 35 packages/min
Weighed Product Dimensions
160mm (L) × 120mm (W)
Display
7-inch OLED high-brightness Chinese touch screen
Conveyor Belt
PU material
Weight Zones
2: qualified, unqualified (multi-zone sorting function optional, requiring external structure and independent configuration)
Frame Material
Stainless steel
Power Supply
AC220V±10%, 50HZ (60HZ)
Motor
Stepper motor, power 50W
Infeed Height Above Ground
380±100mm
Weighing Platform Height Above Ground
200±100mm
Recipe Storage
100 sets of product inspection target recipe data storage
Control System
Industrial embedded computer and real-time operating system
Data Statistics
Product statistics data display, recording and query
Password Protection
3-level password protection, for more comprehensive protection of safe equipment operation
Protection Rating
Overall electrical protection rating IP54
Operating Environment
To ensure the best accuracy, the checkweigher should be installed away from vibration sources and air vents; temperature -10～40℃
Remarks
Weighing accuracy refers to Grade 3 accuracy under specific conditions (on-site factors directly relevant include vibration, interference, etc.)
