① Material storage and feeding: randomly piled materials are poured into the storage bin; the bin is controlled by a photoelectric sensing system and conveys the materials to the lifting unit and the transverse material separating unit.
② Transverse material separation: the transverse material separating unit conveys the materials one by one onto the arranging rollers for arranging, as required by the system.
③ Roller arranging: the arranging rollers consist of 11 drive units with servo drive, photoelectric sensing and motion controller control, performing arranging, rejecting and spacing actions on the materials; rejected materials fall back into the storage bin for reuse, while the properly arranged materials are delivered out of the bag arranging machine one by one in sequence.
④ Direction unification (optional): according to the downstream process requirements for material direction, an optional vision inspection + flipping machine can be provided to unify the material direction.
⑤ Line integration: the bag arranging machine can be combined with cartoning machines, packaging machines, bagging machines, can filling machines, feeding machines and counting and arranging machines to form a complete production and packaging line.
