 【Origin Pic】 |
|
|
|
Product Range
| Material Type | Metering Selection | Machine Packaging Speed | Standard Models (non-standard models customized on request) | Vertical Seal Width & Pattern | Horizontal Seal Width & Pattern | Cutting Blade Type | Front-End Feeding System | Downstream Equipment |
|---|---|---|---|---|---|---|---|---|
| Desiccant industry: silica gel, montmorillonite, minerals, molecular sieves, etc. Also compatible with granular materials such as Isatis root granules. | High-speed drawer-type measuring cup | 1-10 g, 70-80 cuts per minute | Bag width 30mm, 10-lane machine; bag width 32mm, 10-lane machine; bag width 35mm, 9-lane machine; bag width 40mm, 7-lane machine; bag width 45mm, 7-lane machine; bag width 50mm, 6-lane machine; | 5-7mm, straight cross-hatch / diagonal cross-hatch / vertical stripes, pattern pitch 1.2mm. | 5-8mm, straight cross-hatch / diagonal cross-hatch / vertical stripes, pattern pitch 1.2mm. | Straight cutter, serrated cutter, round-corner cutter. | Vacuum feeder | Downstream lifting counting conveyor, fully servo rewinder, box stacking machine. |
| Dehydrogenant industry, single material. Also compatible with granular materials such as Isatis root granules. | High-speed paddle-type measuring cup | 1-5 g, 70-80 cuts per minute | Bag width 35mm, 9-lane machine; bag width 40mm, 7-lane machine; bag width 45mm, 7-lane machine; | 6mm, straight cross-hatch / diagonal cross-hatch, pattern pitch 1mm. | 7mm, straight cross-hatch, pattern pitch 1mm. | Straight cutter | Tunnel-type feeding station | Downstream lifting counting conveyor, fully servo rewinder, box stacking machine. |
| Liquids, fluid materials, paste materials | Liquid ceramic plunger pump | For materials within 1-50 g, max bag width 80mm, max bag length 180mm. Metering speed determined by testing with different materials. | Bag width 30mm, 12-lane machine; bag width 40mm, 10-lane machine; bag width 45mm, 10-lane machine; bag width 50mm, 9-lane machine; bag width 60mm, 8-lane machine; bag width 70mm, 6-lane machine; bag width 80mm, 6-lane machine; | 5-10mm, straight cross-hatch / diagonal cross-hatch / vertical stripes, pattern pitch 1-1.2mm. | 5-12mm, straight cross-hatch / diagonal cross-hatch / vertical stripes, pattern pitch 1.2-1.75mm. | Straight cutter, serrated cutter, round-corner cutter. | Positive/negative pressure liquid storage tanks, top-mounted heated mixing hopper, standard liquid storage hopper | Downstream lifting counting conveyor, fully servo rewinder, box stacking machine. |
| Powder materials | Multi-lane auger weigher | For materials within 1-50 g, max bag width 80mm, max bag length 180mm. Metering speed determined by testing with different materials. | Bag width 30mm, 12-lane machine; bag width 40mm, 10-lane machine; bag width 45mm, 10-lane machine; bag width 50mm, 9-lane machine; bag width 60mm, 8-lane machine; bag width 70mm, 6-lane machine; bag width 80mm, 6-lane machine; | 5-10mm, straight cross-hatch / diagonal cross-hatch / vertical stripes, pattern pitch 1-1.2mm. | 5-12mm, straight cross-hatch / diagonal cross-hatch / vertical stripes, pattern pitch 1.2-1.75mm. | Straight cutter, serrated cutter, round-corner cutter. | Vacuum feeder, screw conveyor. | Downstream lifting counting conveyor, fully servo rewinder, box stacking machine. |
