Core Features
Horizontal bag feeding, stable operation with low noise: horizontal linear bag conveying, with vacuum suction cup bag picking and translation conveying — no bag flipping or jamming; compatible with pre-made bags of 80-320mm, no mold change needed for changeover.
Servo auger precise metering, dust-proof: standard servo auger discharge + hopper stirring with arch-breaking, solving powder bridging and caking; metering accuracy ±1%-±2%, suitable for 5g-3kg; discharge outlet equipped with negative-pressure dust extraction, keeping the bag opening clean and the seal firm.
Multi-station synchronization, efficient mass production: multi-station linkage (bag picking → bag opening → filling → sealing → output), 20-50 bags/min; supports stand-up bags, zipper bags, eight-side seal bags, etc., one machine for multiple bag types.
Full 304 stainless steel, hygienic and easy to clean: material-contact parts in 304 stainless steel, quick-release structure with no dead corners for disassembly and cleaning, compliant with food / pharmaceutical GMP standards; the whole machine is dust-proof and sealed, with little dust in the workshop.
Intelligent control, simple and easy to use: PLC + touchscreen, 50 recipes storable, one-key parameter adjustment; automatic alarm and shutdown for missing bags, failed bag opening, or missed filling — easy for beginners.
Expandable functions: optional screw feeder, inkjet coder, nitrogen flushing device, and vent hole punching, adapting to different preservation and packaging needs.
Applicable Materials
Food: milk powder, protein powder, meal replacement powder, seasoning powder, cocoa powder.
Pharmaceutical: traditional Chinese medicine powder, API powder, medicinal powders.
Daily chemicals: face mask powder, tooth powder, talcum powder.
Chemical: fine powders, additives, pigment powders.
