Reciprocating CS-480S pillow packer

Technical Parameters

Packaging Film Width

Standard Version: 90-420mm
Gusset Version: 90-400mm

Bag Made (L×W×H)

Standard Version: length 90-450mm / width 10-180mm / height 5-60mm
Gusset Version: length 90-450mm / width 35-130mm / height 15-60mm

Packaging Speed

30-120 packs/minute (determined by product shape and size)

Packaging Film Material

PP, PE, PVC, PS, EVA, PET, PVDC+PVC, OPP+composite CPP

Power Supply Type

220V/50Hz

Total Power

7.5kW

Equipment Model

CS-480S (8-servo) Standard Version
CS-480S (8-servo) Gusset Version

Positioning Accuracy

≤±0.5mm

Compressed Air

0.6-0.8MPa 15L/min

Equipment Weight

700kg

Overall Dimensions

4188×918×1630mm (including tail frame)

Product Features

Standard Version Features

Wide applicable width range (10-180mm) and height 5-60mm, capable of packaging small, thin, and lightweight products, suitable for a broader range of product specifications.

Gusset Version Features

Designed specifically for large bag openings and high-thickness products, with the width range narrowed to 35-130mm and the height limit raised to 60mm; combined with the gusset function, it effectively prevents material from spilling out of large bag openings.

Packaging Samples
