Bottled powder filler

Technical Parameters

Brand
Changsheng Packaging Machinery
Scope of Application
Powders and dusts, additives, seasonings, pigment powders, etc.
Metering Method
Auger rotary quantitative type (suitable for filling small granules or powders)
Container Dimensions
Cylindrical containers: diameter 50-200mm, height 50-350mm
Filling Weight
10-5000g (by changing the auger attachment)
Filling Accuracy
For package weight ≤100g, deviation ≤±1g; ≤±1%
Filling Speed
10-30 cans/minute; 1500-4500 bottles/hour
Power Supply
AC 220V/380V, 50Hz
Power
0.9kW to 1.5kW
Overall Dimensions
Approx. 1000×650×2000mm (L×W×H)
Machine Weight
300kg

Structure & Materials and Advantages

Structure and Materials

Stainless Steel Body: all material contact parts are made of 304 stainless steel, complying with GMP and food and pharmaceutical hygiene standards, corrosion-resistant and easy to clean.
Transparent Material Hopper: modular design for easy observation of material status, supporting quick disassembly and cleaning.
Modular Configuration: can be combined with bottle unscramblers, capping machines, labeling machines, and other equipment to form a complete production line, adapting to diverse packaging needs.

Advantages

High Efficiency and Energy Saving: dual-station design increases output, while servo drive reduces energy consumption.
Flexible Adaptation: by changing the auger attachment or adjusting parameters, different materials and packaging specifications can be switched quickly.
Eco-Friendly Design: some models are equipped with a dust extraction device to reduce dust pollution; the anti-drip filling nozzle avoids material waste.

Applicable Materials and Industries

Applicable Materials and Scenarios

Applicable materials: powder medicines, veterinary drugs, milk powder, seasonings, solid beverages, toner, talcum powder, pesticides, and other free-flowing or non-free-flowing powders and small granules.
Packaging Containers: bottles, cans, bags, and other forms, supporting a wide quantitative filling range from 5g to 5000g.

Application Fields

Widely used in food, pharmaceutical, chemical, pesticide, and other industries, particularly suitable for powder packaging scenarios requiring high precision and high cleanliness.

Packaging Samples
