Your position  Home -> Products  ->  Dumpling machine  ->  Dumpling machine

【Origin Pic】

Dumpling machine

Technical Parameters

Machine Model
CS-10A; forming method: wrap-and-close type, 8-station
Dumpling Specification 16g
Wrapper 6-7g, filling 9-10g, 40-60 pieces/min
Dumpling Specification 18g
Wrapper 7-8g, filling 10-11g, 40-60 pieces/min
Dumpling Specification 23g
Wrapper 8-9g, filling 14-15g, 40-60 pieces/min
Discharge Method
Linear electric cylinder push-out
Power Supply Specifications
Single-phase 220V, 50Hz
Dumpling Specification 28g
Wrapper 9-10g, filling 18-19g, 40-50 pieces/min
Dumpling Specification 35g
Wrapper 10-11g, filling 24-25g, 30-40 pieces/min
Dumpling Specification 50g
Wrapper 10-12g, filling 38-40g, 30-35 pieces/min
Air Source Specifications
0.4-0.6MPa, 100L/min
Total Power
4.7kW
Overall Dimensions
1360×1550×1400mm (16-23g); 1400×1660×1600mm (28-50g)
Machine Weight
550kg (16-23g); 650kg (28-50g)

Three Main Model Categories

Small 80/100 Type

Capacity: 4500–6000 pieces/hour, single dumpling weight 14–20g;
Power: 2.2kW/220V, machine weight 110kg, small footprint;
Advantages: compact body, easy to move, suitable for both meat fillings and ordinary vegetable fillings.

130/210 Handmade-Style Type

Capacity: 8000–18000 pieces/hour, dumplings adjustable from 15–35g (large boiled dumplings / steamed dumplings);
Multi-roller layered dough pressing, so the dough does not heat up and the wrappers are springy, with a texture close to handmade;
Frequency-converter speed control, with one-touch adjustment of wrapper thickness and filling amount.

Large Fully Automatic Production Line

Capacity: 20000+ pieces/hour, equipped with a dough mixer, filling mixer, and quick-freezing tunnel to form a complete line; 380V industrial power, all 304 stainless steel body, complying with food GMP standards.

Core Machine Features

One Machine, Multiple Uses: by changing molds, it can make boiled dumplings, potstickers, wontons, spring rolls, and curry puffs.
Ingredient Compatibility: suitable for fresh meat fillings, chive and egg, and three-delicacy fillings with granules; fillings only need moderate moisture content, while soupy fillings are not supported.
Hygienic and Easy to Disassemble for Cleaning: all dough and filling contact parts are 304 stainless steel, and the forming head is quick-release, saving time on cleaning.
Labor Saving: one machine replaces 8–12 dumpling makers, and a single operator can run the whole machine.

Packaging Samples
