Vertical powder packer

Technical Parameters

Packaging Speed
30-80 bags/minute (depending on material and bag type)
Metering Range
10g-1000g
Power Supply / Power
220V/50Hz, power approx. 2-5kW
Air Source Requirement
0.4-0.6MPa (some models require compressed air)
Control System
Integrated functions such as fault alarm, data logging, and remote monitoring
Feeding System
Includes hopper, conveying device, and anti-bridging design (such as an agitator) to ensure smooth material discharge
Metering Device
Auger type (suitable for free-flowing powders) or weighing type (for high-precision requirements) selected according to material characteristics
Packaging Film System
Automatic unwinding, film pulling, and positioning, supporting roll film or pre-made bags
Sealing and Cutting
Heat sealing blade with adjustable temperature and pressure, plus automatic cutter (flat cut or serrated cut)

Main Advantages

High Efficiency and Energy Saving: packaging speeds of up to 30-120 bags/minute, reducing labor costs.
High Precision: low metering error, suitable for high-value materials.
Hygienic and Safe: all-stainless-steel body complying with GMP standards, avoiding contamination.
Flexibility: supports multiple packaging specifications (such as 10g-5kg) and materials (composite film, aluminum foil, etc.).
Stability: automatically detects and rejects non-conforming products, reducing the reject rate.

Applicable Industries

Food: milk powder, coffee powder, seasonings.
Pharmaceutical: granules for infusion, active pharmaceutical ingredients.
Chemical: washing powder, pigments.
Agricultural: fertilizers, feed additives, etc.

Material Types

Free-flowing powders (such as flour and sugar).
Powders prone to caking (requiring anti-caking design).
Ultrafine powders (requiring a dust removal device).

Packaging Styles

Packaging Samples
