CS-700 food metal separator

Equipment Overview

The food and pharmaceutical raw material metal separator is used to detect and separate all metals mixed in food and pharmaceutical raw materials, including ferrous and non-ferrous metals (such as copper, aluminum and stainless steel). During the processing of food and pharmaceutical raw materials, metal impurities may be mixed in, especially stainless steel. If such impurities eventually enter production and cause accidents, the number of shutdowns for maintenance increases, leading to higher costs and reduced production efficiency. In serious cases, they may enter finished products and reach consumers, causing safety accidents and huge claims.

Technical Parameters

Model
SA-700
Discharge Diameter Φ25mm
Throughput 300KG/HR; detection accuracy Φ0.3mm
Discharge Diameter Φ35mm
Throughput 500KG/HR; detection accuracy Φ0.5mm
Discharge Diameter Φ50mm
Throughput 700KG/HR; detection accuracy Φ0.8mm
Working Voltage
220V/50×60Hz
Discharge Time
0.3-5 seconds adjustable
Compressed Air
3~5Bar
Machine Dimensions
390×280×385mm
Box Cover Dimensions
1000×800×800mm
Discharge Diameter Φ65mm
Throughput 1000KG/HR; detection accuracy Φ1.0mm
Discharge Diameter Φ100mm
Throughput 1500KG/HR; detection accuracy Φ1.5mm
Ambient Temperature
-10~+80℃
Structure Material
Full 304 stainless steel, meeting the hygiene requirements of the food and pharmaceutical industries
Channel
Fully enclosed channel, meeting the dust-proof requirements of the food and pharmaceutical industries
Special Customization
Special sizes and requirements can be customized according to customer needs

Product Features & Applicable Industries

Full 304 stainless steel structure, meeting the hygiene requirements of the food and pharmaceutical industries.
Fully enclosed channel, meeting the dust-proof requirements of the food and pharmaceutical industries.
Good detection accuracy with automatic metal separation.
Complies with and meets the requirements of IFS and HACCP certification.

Applicable Industries

Food Industry

Pharmaceutical Industry

Chemical Industry

Other Industries

Packaging Samples
