CS-900 keypad metal detector

Technical Parameters

Model
SAYP-900
Discharge Diameter Φ35mm
Throughput 500KG/HR; detection accuracy Φ0.3mm
Discharge Diameter Φ50mm
Throughput 700KG/HR; detection accuracy Φ0.5mm
Working Voltage
220V/50×60Hz
Ambient Temperature
-10℃~+80℃
Protection Rating
IP65
Inlet Height
750-1080mm
Outlet Height
450-800mm
Adjustable Angle
30-50°
Discharge Diameter Φ65mm
Throughput 800KG/HR; detection accuracy Φ0.8mm
Discharge Diameter Φ100mm
Throughput 1000KG/HR; detection accuracy Φ1.0mm
Rejection Time
0.3-5 seconds adjustable
Frame Material
SUS304
Compressed Air
3-5Bar

Features

Ultra-high sensitivity and stability.
Flat and long-fiber products will not clog the rejection device.
The special structural design effectively avoids interference from external factors such as vibration, noise and product effects.
Multiple diameters available; models to suit all practical applications.
Reasonable design, easy to clean; complies with HACCP, GMP and IFS certification.
Automatic learning function, capable of storing parameters for a variety of different products.

Applicable Industries

Pharmaceutical industry, health product industry, food industry, chemical industry and other industries, for detecting metal impurities mixed into products or raw materials during production and processing, such as iron and non-ferromagnetic metal objects (non-ferrous metals such as iron, copper, aluminum and stainless steel can all be detected), improving product safety and enhancing corporate product quality.

Packaging Samples
